Powered Torque Wrench
Powered Torque Wrench, is also called "Electric Torque Wrench".A power tool is a tool that is actuated by an additional power source and mechanism other than the solely manual labor used with hand tools. Today we will show you TL-3B, TL-5B and TL-9B three models Powered Torque Wrenche
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
A power tool is a tool that is actuated by an additional power source and mechanism other than the solely manual labor used with hand tools.
The following video will show you the application of three of our Powered Torque Wrenches in one bridge construction --- Jinan Phoenix Road Yellow River Bridge.
Features:
L-shape Reaction arm ;
Digital screen ;
Easy torque set switch ;
Accurate to ± 2% ;
Double-insulated, low noise ;
110-120V, 220-230V models .
How does a Powered Torque Wrench work?
Electronic or Digital torque wrenches have a digital readout screen which allows the user to preset the torque limit. A strain gauge which is attached to a torsion rod sends a signal to a transducer to determine the force of torque per unit, which is then displayed via the LED reading.
What should you not do with a Powered torque wrench?
Do not drop your torque wrench or overload the wrench with a pipe extension. Improper Wrench Storage - Storing the torque wrench in conditions that will lead to the corrosion in the tool.
Users should never put a pipe or any other kind of extension onto a torque wrench handle as doing so can seriously damage the tool and make it inaccurate, never mind the potential safety hazard.
The Electric Torque Wrench can be used to tighten and loosen bolts. Turn the mechanical steering gear to T to tighten bolts and trun to L to loosen bolts.
These three Powered Torque Wrenches adopt standard square drive , thus there is no need to worry about where to buy the sockets.
| Model | Voltage | Max Current | Power Rating | Torque Range (N.m) | Speed (rpm/min) | Weight (kg) | Square Drive | Adaptable Bolts | ||
| S-10T | A325 | A490 | ||||||||
| TL-3B | 230V 115V | 6A 12A | 1300W | 100-300 | 24.0 | 4.4 | 19*19mm (3/4''*3/4'') | M12 M16 | 1/2'' 5/8'' | 1/2'' |
| TL-5B | 7A 14A | 1650W | 200-500 | 15.5 | 4.5 | M16 M20 | 5/8'' 3/4'' | 5/8'' | ||
| TL-9B | 400-900 | 9.5 | 5.3 | 25.4*25.4mm (1''*1'') | M20 M22 M24 | 3/4'' 7/8'' 1'' | 3/4'' 7/8'' | |||
CE Certificate ：
Other models in L-series Powered Torque Wrenches.
Complete inventory system : All models and spare parts currently sold are available from stock throughout the year.
Reach me here for more information .
